產品 · 簡介
TABR系列性能參數表/TABR Series Performance Table | |||||||
規格 Specification | 單位 Unit | 節數 Stage | 減速比 Ratio | TABR60 | TABR90 | TABR115 | TABR142 |
額定輸出力矩/Rated output torqueT2N | Nm | 1 | 3 | 36 | 90 | 195 | 342 |
4 | 48 | 120 | 260 | 520 | |||
5 | 60 | 150 | 325 | 650 | |||
6 | 55 | 150 | 310 | 600 | |||
7 | 50 | 140 | 300 | 550 | |||
8 | 45 | 120 | 260 | 500 | |||
10 | 40 | 100 | 230 | 450 | |||
2 | 15 | 60 | 150 | 325 | 650 | ||
25 | 60 | 150 | 325 | 650 | |||
30 | 55 | 150 | 310 | 600 | |||
35 | 50 | 140 | 300 | 550 | |||
40 | 45 | 120 | 260 | 500 | |||
45 | 40 | 100 | 230 | 450 | |||
50 | 60 | 100 | 230 | 650 | |||
60 | 55 | 150 | 310 | 600 | |||
70 | 50 | 140 | 300 | 550 | |||
80 | 45 | 120 | 260 | 500 | |||
90 | 40 | 100 | 230 | 450 | |||
100 | 40 | 100 | 230 | 450 | |||
急停扭矩 /Emergency stop torqueT2NOT | Nm | 1,2 | 3-100 | 三倍額定輸出力矩/Triple rated output torque | |||
額定輸入轉速/Rated input speed η1N | rpm | 1,2 | 3-100 | 5000 | 4000 | 4000 | 3000 |
******輸入轉速/Maximum input speed η1B | rpm | 1,2 | 3-100 | 10000 | 8000 | 8000 | 6000 |
扭轉剛性 /Torsional rigidity | Nm/arcmin | 1,2 | 3-100 | 7 | 14 | 25 | 50 |
容許徑向力/Allowable radial forceF2aB | N | 1,2 | 3-100 | 1530 | 3250 | 6700 | 9400 |
容許軸向力/Allowable axial forceF2aB | N | 1,2 | 3-100 | 765 | 1625 | 3350 | 4700 |
使用壽命/Lifespan | hr | 1,2 | 3-100 | 20000 * | |||
效率 /Efficiency | % | 3~10 | ≥95% | ||||
2 | 15?100 | ≥92% | |||||
重量 /Weight | kg | 1 | 3~10 | 2.1 | 6.4 | 13 | 24.5 |
2 | 15?100 | 1.5 | 7.8 | 14.2 | 27.5 | ||
使用溫度 /Working temperature | °C | 1,2 | 3-100 | (-10° C +90° C ) | |||
潤滑 /Lubricating | 合成潤滑脂 /Synthetic lubricating grease | ||||||
防護等級/IP Grade | 1,2 | 3-100 | IP65 | ||||
安裝方向 /Installation direction | 1,2 | 3-100 | 任意方向 /In any direction | ||||
噪音值(η1 =3000rpm,無負載) Noise level (η1 =3000rpm,off load) | dB(A) | 1,2 | 3-100 | ≤63 | ≤65 | ≤68 | ≤70 |
